STUDIO SOUND DEPARTMENT

Mixing |​ Sound Reinforcement | Microphones

SOUNDSTAGE A    ACOUSTICS

DJI Osmo Pocket 3 Camera Walkthrough
(Turn it up! - Headphones or Buds are fun/best.)

Soundstage A Sound Reinforcement  (Speakers)

3-way stereo line array system with subwoofers

(16) Electro-Voice XLD281, 120 degree horizontal, line array elements (8 per side - Flown)
(4) Electro-Voice X12i dual 18” Super-high-output subwoofer cabinets (2 cabinets per side - 8 total 18" subwoofers - Stage L/R Deck)
(16) Electro-Voice V TG7 power amplifiers with RCM-26 DSP control modules

YAMAHA QL5
LIVE MIXING CONSOLE

64-Channel Digital Mixing Console
1 RIOS S32 x 16 Dante digital stage box
1 RIOS S16 x 8 Dante digital stage box
Electro-Voice IRIS-net control software (DSP control for TG7 amplifiers)
(1) dbx Driverack 260 for subwoofer crossover and processing

STAGE MONITORS: 8 Electro-Voice Tour-X TX1122FM passive 2-way floor monitors
6 discrete monitor mixes.  Monitors are mixed from the FOH console.  Separate monitor console available upon request.3 - Behringer X32 digital mixing consoles (Monitors) (firmware version 2.10)

DIRECT Boxes: 2 Radial JDI Duplex 2-channel direct box
2 Radial ProDI
2 Radial Pro48
2 Whirlwind EDB1 direct box

INTERCOM:
1 - Clearcom FreeSpeek II Wireless Intercom, 4 antenna system
15 - Clearcom FreeSpeek II Wireless 5 Channel Beltpacks

INTERCOM
WIRELESS | WIRED | GLOBAL


RTS ODEN
Dante digital 48 port intercom.

CLEARCOM
Matrix Intercom Systems
(Coupled to Oden)
8 - 16 channel programmable user stations in unit. (Audio, AD, Producer, Director, TD, Video, Lighting, FOH)
15 - RTS Two Channel Wired Beltpacks.

IFB
4 channels IFB interrupt, (located on Producer/Director/AD user stations)
4 Wired IFB
2 - Shure PCM 900 Wireless Monitor System.
P9T Transmitter and PR9A+ Wireless Bodypack Receiver.

FREESPEAK I I
Digital Wireless Intercom.
(Coupled to Oden)
5 Channels wireless.
1.9 GHz Dect 6.0
15 Wireless Beltpack Stations.
1 to 6 dedicated to camera department. (Based on # of cameras used)
Network Antenna System. 4 antenna units - allows arena size coverage for 20 wireless stations.

David Clark Headsets
 "Loud Environment" headsets for camera operations.


 UNITY INTERCOM
Connects globally over WIFI and cellular.
Self-Hosted Server Version.
Integrates with RTS Oden via DANTE

microphones

STUDIO | LIVE PERFORMANCE | LOCATION
OVER 100 CLASSIC MICROPHONES

WIRELESS Microphones: (14 Systems)
2 Shure G-50 ULXD4 Quad Receivers (8 total channels)
8 Shure G-50 ULXD2 K8B capsules handheld transmitters
2 Shure G-50  ULXD1 beltpack transmitters
6 Sennheiser G-2 ew300 Series Receivers
4 Sennheiser G-2 handheld transmitters (3 x 835 capsules, 1x 865 capsule)
4 Sennheiser G-2 beltpack transmitters
4 Audio Technica AT898 cardioid lavalier microphones
2 Sennheiser MKE2 omnidirectional lavalier microphones
2 Sennheiser ME 2 omnidirectional lavalier microphones
2 Sennheiser HSP2 omnidirectional headset microphones
 WIRED Microphones: Stage & Studio2 AKG C451 Stereo Pair (Instrument) Small-Diaphragm Condenser
1 AKG D12 VR (Kick/Base) Dynamic
1 AKG D112 (Kick/Base) Dynamic
2 Audio Technica AT857  (Podium)
2 Audio Technica AT815ST Stereo Long Throw Shotguns, Zeppelins and Dead Cats
3 Audix OM7 (Vocal) Hypercardioid
1 EV RE20 (Vocal/Instrument) Dynamic Cardioid
1 EV RE27 (Vocal/Instrument) Dynamic Cardioid
1 Neumann KMS 105 Black - (Vocal Hand)
1 Neumann KMS 105 Nickel Silver - (Vocal Hand)
2 Neumann KM 184 Black Stereo Pair - (Instrument) Small-Diaphragm Condenser
2 Neumann TLM 107 Black Stereo Pair - (Vocal/Instrument) Large-Diaphragm
1 Neumann U 87 Ai (Vocal/Instrument) Large-Diaphragm Condenser
3 Rode NT1000 (Vocal/Instrument) Large Diaphragm Condenser
3 Sennheiser MD 421-II (Vocal/Instrument) (Drums) Cardioid
1 Sennheiser MD 441-U (Vocal/Instrument) Super Cardioid
1 Sennheiser MK4 (Vocal/Instrument) Large Diaphragm Condenser
5 Sennheiser e609 (Instrument/Guitar) Super-Cardioid
5 Sennheiser e835 (Vocal Hand) Dynamic Cardioid
4 Sennheiser e904 (Drums) Cardioid Dynamic
1 Sennheiser e906 (Instrument) Super-Cardioid
1 Sennheiser e914 (Instrument) Small-Diaphragm Condenser Cardioid
5 Shure SM 27 (Vocal/Instrument) Large Diaphragm Cardioid
1 Shure Super 55 (Dynamic (Vintage - Elvis)
7 Shure SM 57 (Instrument) Cardioid Dynamic
4 Shure SM 58 (Vocal Hand) Cardioid Dynamic
2 Shure SM 58s (Vocal Hand) Cardioid Dynamic w/Switch
5 Shure Beta 87A (Vocal Hand/Instrument) Super-Cardioid

WILD AND SYNC​ SOUND DESIGN

Zoom F8n Pro Field Recorder/Mixer 8 input/10 tracks w/Timecode
 1 Schoeps CMC 6  | MK 41 Supercardioid Condenser and Cinela Windshield
 1 Sennheiser MKH 816T-F Shotgun Mic and Windshield
 1 Sennheiser MKH 416 Shotgun Mic and Windshield
 2 Sennheiser MKH 8040 Stereo Pair Mic's - Condenser
 1 Cinela ALBERT ORTF-8000 Windshield for Sennheiser MKH 8040's
 2 Auray BP-28CC Carbon Fiber Boompole 7.7' and 20'

SOUNDSTAGE B SOUND REINFORC​EMENT

Compact Line Array System

Stereo R6/R12a Compact Active Line Array System
3000W amplifiers per side
Grid Flown
Behringer X32 digital mixing console
Monitors are mixed from the FOH console.  Separate monitor console available upon request.
